W.A.R. FW-190
RoleHomebuilt aircraft
National originUnited States
ManufacturerWar Aircraft Replicas International, Inc.
First flight21 August 1974
War

The W.A.R. FW-190 is a half-scale homebuilt replica of a Focke-Wulf Fw 190 fighter. In July 1973, War Aircraft Replicas International of Santa Paula, California began design of an approximately half-scale replica of the Fw 190, the first of a series of replicas of World War II aircraft using similar constructional techniques. The first prototype made its maiden flight on 21 August 1974.[1][2][3][4][5]

Design and development[edit]

The aircraft structure is based on a wooden framework for the fuselage and wings, using polyurethane foam to build up the fuselage shape and wing aerofoil profile, with a fabric/epoxy covering. The aircraft is fitted with an electrically retractable tailwheel undercarriage to match the configuration of the original aircraft. The initial powerplant specified was a 1600 cc Volkswagen air-cooled engine of 70 hp (52 kW), driving a three-bladed fixed pitch propeller. Small Continental Motors, Inc. and Lycoming Engines of 100 to 120 hp (75 to 89 kW) have commonly been used.[1][2][5]

WarFw 190 A5 War Thunder

The prototype aircraft was displayed at the Experimental Aircraft Association convention in 1974. Realistic details such as simulated fabric surfaces, and detailed smoke trails were noted, the aircraft drew a large amount of attention at the show.[6]

190

A special U12 was created for bomber attack, outfitted with the standard 7.92 mm (0.312 in) MG 17 and 20 mm MG 151 but replacing the outer wing 20 mm MG-FF cannon with two underwing gun pods containing two 20 mm MG 151/20 each, for a total of two machine guns and six cannon. A few paragraphs on aircraft history, design, development, employment, and other notable facts. 1 Specifications 1.1 Performance 1.2 Armament 2 Utilization and Tactics 2.1 Piloting the Aircraft 2.2 Flying Against 3 Variant Models 3.1 Model 1 3.2 Model 2 4 Operational History 5 Image Gallery Maximum Speed: Maximum Altitude: Turn Time: Rate of Climb: Takeoff Run: Primary Weapons Secondary.

At least 197 sets of plans had been sold by 1982,[1] and plans remain on sale from War Aircraft Replicas, now based in Florida.[7]

Variants[edit]

Some versions were built using 125 hp (93 kW) Lycoming O-235 and 123 hp (92 kW) HCI radial engines.

Specifications (W.A.R. FW-190)[edit]

Data from Jane's All The World's Aircraft 1988–89[8]

General characteristics

  • Crew: 1
  • Length: 16 ft 7 in (5.05 m)
  • Wingspan: 20 ft 0 in (6.10 m)
  • Height: 7 ft 0 in (2.13 m)
  • Wing area: 70.0 sq ft (6.50 m2)
  • Empty weight: 630 lb (286 kg)
  • Max takeoff weight: 900 lb (408 kg)
  • Fuel capacity: 10 US Gallons, 38 L
  • Powerplant: 1 × Continental O-200 air cooled flat-four, 100 hp (75 kW)

Performance

  • Maximum speed: 169 kn (194 mph, 313 km/h) at 3,500 ft (1,070 m)
  • Cruise speed: 108 kn (124 mph, 200 km/h) (econ cruise)
  • Stall speed: 48 kn (55 mph, 89 km/h)
  • Range: 347 nmi (399 mi, 643 km)
  • Service ceiling: 12,500 ft (3,800 m)
  • Rate of climb: 1,000 ft/min (5.1 m/s)
  • Wing loading: 12 lb/sq ft (59 kg/m2)

Notes[edit]

  1. ^ abcTaylor 1982, p. 582.
  2. ^ abPlane and Pilot: 1978 Aircraft Directory, page 159. Werner & Werner Corp, Santa Monica CA, 1977. ISBN0-918312-00-0
  3. ^Downey, Julia: 1999 Plans Aircraft Directory, Kitplanes, Volume 16, Number 1, January 1999, page 71. Primedia Publications. ISSN0891-1851
  4. ^Purdy, Don: AeroCrafter - Homebuilt Aircraft Sourcebook, page 291-2. BAI Communications. ISBN0-9636409-4-1
  5. ^ abBayerl, Robby; Martin Berkemeier; et al: World Directory of Leisure Aviation 2011-12, page 126. WDLA UK, Lancaster UK, 2011. ISSN1368-485X
  6. ^Jack Cox (Nov 1974). 'It's W.A.R.!'. Sport Aviation.
  7. ^WAR Replicas. Retrieved 9 July 2010.
  8. ^Taylor 1988, p. 612.

References[edit]

  • Taylor, John W. R.Jane's All The World's Aircraft 1982–83. London:Jane's Yearbooks, 1982. ISBN0-7106-0748-2.
  • Taylor, John W. R. Jane's All The World's Aircraft 1988–89. Coulsdon, UK:Jane's Defence Data, 1988. ISBN0-7106-0867-5.
  • Dean Clark (February 1979). 'Dean Clarks FW.190'. Sport Aviation.
  • Kitplanes. Aug 2001.Missing or empty title= (help)
  • Recreational Flyer. Nov 1988.Missing or empty title= (help)
  • Recreational Flyer. Fall 1987.Missing or empty title= (help)
  • Popular Mechanics. Jan 1981.Missing or empty title= (help)
  • Popular Flying. Nov 1981.Missing or empty title= (help)
  • Homebuilt Aircraft. Nov 1980.Missing or empty title= (help)
  • Popular Mechanics. Jan 1980.Missing or empty title= (help)
